Technical parameter | JT10L-606QC | JT16L-606 QC |
Pesticide load | 10 liters | 16 liters |
Self weight | 10.5 kg | 17 kg |
Take-off weight | 24.5 kg | 40 kg |
Fly time | 10~15 min | 10~15 min |
Spraying efficiency | 5~7 hectares/hour | 8~10 hectares/hour |
Spray width | 4~6 m | 6~7 m |
Spray speed | 0~8 m/s | 0~10 m/s |
Nozzle | 4 high pressure nozzles | 4 high pressure nozzles |
Battery | 2 pcs 6S 17000 mAh | 1 set * 12S 22000 mAh |
Flying radius | 1000 m | 1000 m |
Spray flow | 1~1.5 L/min | 2~ 2.5 L/min |
Flying height | 0~30 m | 0~30 m |
Work temperature | –10~70 ℃ | –10~70 ℃ |
Work humidity conditions | 0~90% | 0~90% |
Wind resistance | 10 m/s | 10 m/s |
Spread size (m) | 1.5 *1.5 * 0.6 m | 1.8 *1.8 * 0.7 m |
Folded size (m) | 0.9 * 0.8 *0.6 | 0.95 * 1.05 *0.7 m |
Aluminum box size / weight | 100*90*80 cm / 50 kgs | 120*100*80 cm / 80 kgs |
